Lorex IP & PoE over Coax
Best upgrade solution for existing coaxial camera systems.
$199.99
at
Lorex Corporation
Who it's for
- Homeowners or businesses with existing coaxial cabling infrastructure.
- Installers seeking to reduce wiring complexity and installation time.
- Budget-conscious users wanting to modernize their security system.
Who should skip it
- Users planning multi-camera setups on a single cable run.
- Tech-savvy users demanding maximum network performance for their cameras.
- Minimalists preferring direct connections to reduce system intricacy.
Key Specs
Model
ECP-01T / ECP-01R
Interface
1 x 75Ω BNC (Female) - Ethernet over Coax (B-LinX) / 1 x RJ45 - 100 Base-T
Transmission Rate
100Mbps Full Duplex (100Mbps between Intercoax devices)
Transmission Distance
Ethernet up to 400 m (100Mbps) / up to 1000 m (10Mbps) (5C-HFBT, RG-59 or better)
PoE (PoC) Distance
Up to 400 meters (RG-59, RG-6)
LED Indication
Ethernet - 1 x Link (Yellow) / 1 x ACT (Green)
Power Input
B-Linx or DC48V~57V (Transmitter) / PoE Switch or DC48V~57V (Receiver)
PoE Output
IEEE802.3af (PoE), IEEE802.3at (PoE+), Extra PoE up to 60W with 57V Power Adaptor (Transmitter)
Dimension
83(L) x 51(W) x 24(H)mm
Weight
52g
