Who it's for
- Compact Project Footprint
- Accessible Integration for Makers
- Budget-Friendly Interface Solution
Who should skip it
- Limited Touch Responsiveness
- Moderate Pixel Density
- Narrow Viewing Angle Limitations
Key Specs
Display Size
4.3" TFT LCD Module
Resolution
480X272
Controller Chip
SSD1963
Interface
8/16bit parallel bus interface
Active Area
95.06mm x 52.86mm
Pixel Pitch
0.135mm x 0.135mm
Connection
Standard 2x20 2.54mm pin header
Backlight Power
On board DC-DC Boost regulator TPS61040
